Nominal and dynamic on-die termination odt for data, strobe, and mask signals. Low-power auto self refresh lpasr . Data bus inversion dbi for data bus. On-die vrefdq generation and calibration. Dual-rank. On-board i2 serial presence-detect spd eeprom. Fixed burst chop bc of 4 and burst length bl of 8 via the mode register set mrs . Selectable bc4 or bl8 on-the-fly otf . Terminated control command and address bus. Valueram, kingston’s industry standard memory, delivers award-winning performance and legendary kingston reliability. When you know what you want, you want valueram.. Features. Jedec standard. Yes. Country of origin. Taiwan. Programming power voltage vpp . 2.5 V. Row active time. 32 Ns. Refresh row cycle time. 350 Ns. Row cycle time. 45.75 Ns. Memory voltage. 1.2 V. Memory data transfer rate. 3200 Mt s. Cas latency. 22. Ecc. No. Memory form factor. 260-Pin so-dimm. Component for. Laptop. Internal memory type. Ddr4. Memory layout modules x size . 1 X 32 gb. Internal memory. 32 Gb. Buffered memory type. Unregistered unbuffered . Operational conditions. Storage temperature t-t . -55
100 C. Operating temperature t-t . 0
85 C. General. Product family. Valueram. Technical details. Compliance certificates. Rohs. Sustainability. Doesn't contain. Halogen. Weight & dimensions. Height. 30 Mm. Depth. 3.7 Mm. Width. 69.6 Mm. Logistics data. Harmonized system hs code. 84733020. Leaflet
Brand: Kingston Technology
Type: Memory Modules
Shipping Cost: DKK 0.00
Delivery Time: 3-5 working days
Nominal and dynamic on-die termination odt for data, strobe, and mask signals. Low-power auto self refresh lpasr . Data bus inversion dbi for data bus.
